Mfr

Panasonic Electronic Components

Series

EXB

Circuit Type

Isolated

Resistance (Ohms)

33

Tolerance

±5%

Number of Resistors

4

Resistor Matching Ratio

-

Resistor-Ratio-Drift

-

Number of Pins

8

Power Per Element

62.5mW

Temperature Coefficient

±200ppm/°C

Operating Temperature

-55°C ~ 125°C

Applications

Automotive AEC-Q200

Mounting Type

Surface Mount

Package / Case

0804, Convex, Long Side Terminals

Supplier Device Package

0804

Size / Dimension

0.079" L x 0.039" W (2.00mm x 1.00mm)

Height - Seated (Max)

0.018" (0.45mm)

Base Product Number

EXB-28
