Mfr

Panasonic Electronic Components

Series

EXB

Circuit Type

Bussed

Resistance (Ohms)

22k

Tolerance

±5%

Number of Resistors

8

Resistor Matching Ratio

-

Resistor-Ratio-Drift

-

Number of Pins

10

Power Per Element

50mW

Temperature Coefficient

±200ppm/°C

Operating Temperature

-55°C ~ 125°C

Applications

-

Mounting Type

Surface Mount

Package / Case

1206 (3216 Metric), Concave, Long Side Terminals

Supplier Device Package

1206

Size / Dimension

0.126" L x 0.063" W (3.20mm x 1.60mm)

Height - Seated (Max)

0.026" (0.65mm)

Base Product Number

EXB-D10
